Medical transfer ambulance

It is a Medical transfer ambulance designed to transport medical, injured or sick people to hospital and provide medical care to patients at a distance and emergency care to people with acute medical problems. We can provide patient transfer ambulance, ward ambulance and negative pressure ambulance. We can also customize vehicles according to customer requirements to meet customer practical needs!

Send Inquiry

Product Description


Medical transfer ambulance presentation

The vehicle design is beautiful in appearance and smooth in line. The cab is safe and comfortable, the vehicle has good handling performance and good damping performance. The medical cabin has a spacious space and a reasonable and smooth layout to ensure the safety and comfort of patients, as well as the convenience of medical staff. The car for the whole box structure and partition wall will be divided into car cab and medical class two parts, partition wall horizontal well versed in the whole body, the upper wall is equipped with a visual observation window, former aft equipped with intercom system, medical capsule in addition to the side sliding door and end for the transparent glass door window (the window stick kingbox solar film), the rest of the Windows closed, cab and medical cabin air conditioning system, There are air heaters in the medical bay. Slender vertical taillights are placed on both sides of the rear to enhance the visual effect while ensuring a wide rear door opening. The tail door adopts the open-type design, which can facilitate the medical staff to get up and down the patients in need of rescue, taking into account the convenience of medical staff operation, saving time and effort, so as to improve the work efficiency of medical staff.

Product parameters

Curb weight (kg) 2540
Axle loading(kg) 1560/1935
Overall dimension(mm) 5580*2000*2540
Medical treatment cabin dimension(mm) 2800*1770*1850
Approach/departure angle(°) 20/25
Max speed (km/h) 156
Front/Rear overhang (mm) 1014/1027
Color According to customer’s request
Chassis Parameters
Chassis name Ford,JMC,jinbei,other famous brand
Number of axles 2
Wheel base(mm) 3300
Cabin seats 6passengers
Gear box 6speed,5forward 1rear
Number of wheels 2
Tire specification 215/75R16LT
Front Track (mm) 1736
Rear Track (mm) 1720
Engine Parameters
Engine model DURATORQ4D2O5L
Engine type 2.0T, four-cylinder, supercharged intercooled, high pressure common rail
Drive type 4*2,Left hand drive
Emission standard Euro 5
Displacement (ml) 1998ml/121kw
Power horse(hp) 165
Fuel Type Diesel
Configurations Instruction
Warning system Warning light,alarm and flash lights
Power system 1000W positive wave inverter system
Integrated circuit integrated control protection system
Ac circuit protection system
Integrated switch control panel for medical module
GB 220V power port,Disinfecting lamp,Ventilator,Intercom
Oxygen pathway and oxygen Two 10-liter medical oxygen bottles with shock absorbing clamp,concealed oxygen piping system,two oxygen ports,one humidifier
bottle
Medical cabin Polymer hard top;polymer material partition wall;long hanging cabinet and medical equipment and storage cabinet;Vertical oxygen
tank cabinet;full set of blue anti-collision soft cover walls
Seats 1PCS Reverse soft roll seat,1PCS Independent seat with backrest,1PCS long soft roll seat for 2 person
Emergency auxiliary Stretcher pad and guide plate,1pcs slideable infusion rack,fire extinguisher
Appearances Black solar membrane on left side,translucent frosting film on right and rear side

Product features and applications

Our ambulance adopts the bearing type boron steel reinforced body structure, high strength galvanized plate, which can effectively absorb the impact brought by impact and achieve higher yield strength. Streamline appearance, driving can effectively guide the surrounding air flow, reduce air resistance and fuel consumption, help to improve the stability of the car driving and engine cooling conditions, with good ventilation inside the body. The style of the new dashboard is simple and clear, the display of speed, speed, water temperature, fuel tank and mileage is clear at a glance, but also added the intimate reminder function of the remaining mileage of fuel consumption. Even at night, the white-lettering on a black background paired with the ice-blue gauge hand is very effective. The exterior shape, interior layout and space are abundant and flexible, and the planning of driving and riding space is reasonable to meet the needs of "versatility".

Product details



Company size



Delivery of shipments and services



FAQ

Q1 How to place an order?
1) Contact customer service to confirm the freight and product model, configuration, quantity and other details (you can also arrange your own freight forwarder);
2) We provide you with a proforma invoice containing all product details in accordance with your final decision;
3) You need to arrange 30% payment to our bank account, then we will prepare the product to start production (the cycle is generally about 10 days, can be specially configured for your order quantity delivery);
4) After the product is completed, we will pay the remaining payment and arrange delivery by our forwarder (or we can provide relevant information and arrange forwarder transportation by ourselves).
5) Upon completion of this process, customer service will track the location of the product and notify you of its imminent arrival and arrival so that you can quickly prepare for customs clearance and other related issues.

Q2 What does your FOB reference price include?
A: FOB includes costs only. If you do not have your own freight forwarder, please provide us with the port country/region near you and we will quote cif including freight.

Q3 What is your warranty service?
A: We offer a one-year warranty for the motors, batteries and controllers.

Q4 Why can't I use Courier service and order by myself?
A: Packaged, the product is bulky and contains a large number of batteries. It can be transported by rail but the cost is too high (the appearance of the product may wear out).

Q5 What if I still insist on home delivery?
A: Please provide your address and then we can check the details and arrange.

Q6 What is your production/delivery time for ?
A: The production/delivery time will be controlled within 30 days (generally 10 days can be shipped, simple configuration is 2-3 days).

Q7 Do you test everything before shipping?
A: Yes, we have passed 100% testing before shipment (basic equipment testing also includes roads, hill climbing, rain, water crossing roads, etc.).

Q8 Do you support sample shipment?
A: Yes, we support shipping samples to the port.

Q9 how to guarantee my order after placing order?
A: We will track your order and provide production videos throughout the process. After delivery, the location of the item will also be tracked and provided to you until you receive the item. There will also be a dedicated customer service to receive your follow-up feedback.

Q10 Can you produce Q10 according to the sample?
A: Yes, we can produce according to your samples or technical drawings. We can build molds and fixtures.

Q11 What are your payment terms?
Answer: 30% as deposit, and pay 70% balance before delivery. We will show you photos and videos of the products and packaging before
