Electric self loading and unloading garbage truck

We provide professional sanitation garbage truck and sanitation garbage truck with complete specifications and high cost performance. This small electric self loading and unloading garbage truck adopts manganese steel cold riveting splicing process light truck load chassis, matched with standard automobile tires and shock absorbers. It has strong load capacity and compact body. It can adapt to the road conditions with narrow roads and more parking in residential areas. Moreover, the vehicle is pure electric and has low operation noise, which does not affect the life of surrounding residents. We are committed to the R & D, manufacturing and sales of electric sanitation vehicles for many years, deeply ploughing the Chinese market and covering most markets in Europe and Southeast Asia. We look forward to becoming your long-term partner in China.

Send Inquiry

Product Description


product presentation

This small electric self loading and unloading garbage truck is equipped with a first-line brand maintenance free battery, with a range of up to 100 kilometers, which meets the needs of large area and long cleaning and transportation distance of the scenic spot. Moreover, the whole car is pure electric and has zero emission, which will not pollute the environment of the scenic spot. At the same time, it is also equipped with EPS steering assist device, EBS braking vacuum assist system and widened front and rear hydraulic braking. It has flexible steering, reliable braking and safer driving in the scenic spot.

Product parameters

Items Spec
Vehicle size 4250mmx1450mm x2120mm
Body volume(m³) 3.6
GVW(kg) 3500
Capacity(kg) 1300
Wheelbase(mm) 2210 mm
Tire size 185R14LT
Traveling motor power(KW) 7.5
Pump motor power(KW) 2.2
Climbing ability(%) 30
Battery capacity(Kwh) 14.4(lithium battery)
28.8 (lithium battery)Optional
Mileage(km) 60~80(14.4Kwh)
120~150(28.8Kwh Lithium)optional
Promote capacity(kg) 300 kg
Compression capacity 1:1.5
Sigle promote capacity EN840 120L/240L/360L
Double promote capacity
(optional)
EN840 120L/240L,360L/660L(sigle)
Unloading time(s) 35±1
Promote time(s) 10±1
Camera system Yes
Air conditioner Yes

Product features and applications

This small electric self loading and unloading garbage truck adopts a hydraulic tail plate with strong bearing capacity. It can lift two 240L standard garbage cans or one 600L large garbage can at the same time. At the same time, it has a scraper, which can effectively use the storage space through two gentle compression. After taking away the garbage, put the garbage can back in place to meet the needs of large amount of garbage and large demand for garbage cans in the commercial street. At the same time, this small electric self loading and unloading garbage truck adopts a forward tilting carriage and has an independent sewage discharge outlet. It will not cause secondary pollution in the process of cleaning and transportation, and can effectively protect the environment. At present, it has been widely used in urban sanitation, urban and rural sanitation, municipal gardens, property cleaning, factories, schools, hospitals, scenic spots, communities, streets and other places.

Product details





Company size



Delivery of shipments and services



FAQ

Q1 How to place an order?
1) Contact customer service to confirm the freight and product model, configuration, quantity and other details (you can also arrange your own freight forwarder);
2) We provide you with a proforma invoice containing all product details in accordance with your final decision;
3) You need to arrange 30% payment to our bank account, then we will prepare the product to start production (the cycle is generally about 10 days, can be specially configured for your order quantity delivery);
4) After the product is completed, we will pay the remaining payment and arrange delivery by our forwarder (or we can provide relevant information and arrange forwarder transportation by ourselves).
5) Upon completion of this process, customer service will track the location of the product and notify you of its imminent arrival and arrival so that you can quickly prepare for customs clearance and other related issues.

Q2 What does your FOB reference price include?
A: FOB includes costs only. If you do not have your own freight forwarder, please provide us with the port country/region near you and we will quote cif including freight.

Q3 What is your warranty service?
A: We offer a one-year warranty for the motors, batteries and controllers.

Q4 Why can't I use Courier service and order by myself?
A: Packaged, the product is bulky and contains a large number of batteries. It can be transported by rail but the cost is too high (the appearance of the product may wear out).

Q5 What if I still insist on home delivery?
A: Please provide your address and then we can check the details and arrange.

Q6 What is your production/delivery time for ?
A: The production/delivery time will be controlled within 30 days (generally 10 days can be shipped, simple configuration is 2-3 days).

Q7 Do you test everything before shipping?
A: Yes, we have passed 100% testing before shipment (basic equipment testing also includes roads, hill climbing, rain, water crossing roads, etc.).

Q8 Do you support sample shipment?
A: Yes, we support shipping samples to the port.

Q9 how to guarantee my order after placing order?
A: We will track your order and provide production videos throughout the process. After delivery, the location of the item will also be tracked and provided to you until you receive the item. There will also be a dedicated customer service to receive your follow-up feedback.

Q10 Can you produce Q10 according to the sample?
A: Yes, we can produce according to your samples or technical drawings. We can build molds and fixtures.

Q11 What are your payment terms?
Answer: 30% as deposit, and pay 70% balance before delivery. We will show you photos and videos of the products and packaging before
